Baynunah 2010

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
بينونه [Baynunah]	P171		CMN, Cherbourg, France	8.9.2005	25.6.2009	2012	in service (2020)
الحسن [Al Hesen]	P172		ADSB Massafah, Abu Dhabi	5.7.2006	22.7.2010	5/2013	in service (2020)
الظفرة [Al Dhafra]	P173		ADSB Massafah, Abu Dhabi	21.6.2007	3.4.2011	24.12.2013	in service (2020)
مزيد [Mezyad]	P174		ADSB Massafah, Abu Dhabi	5.12.2007	15.2.2012	10.5.2016	in service (2020)
الجاهلي [Al Jahili]	P175		ADSB Massafah, Abu Dhabi	26.10.2008	13.3.2013	2016	in service (2020)
الهيلي [Al Hili]	P176		ADSB Massafah, Abu Dhabi	27.9.2009	8.2.2014	2016	in service (2020)

Technical data

Displacement standard, t	840
Displacement full, t	915
Length, m	67.0 pp 71.5 oa
Breadth, m	11.0
Draught, m	2.90
No of shafts	3 waterjets
Machinery	4 MTU 12V595 TE90 diesels
Power, h. p.	22800
Max speed, kts	32
Fuel, t	diesel oil
Endurance, nm(kts)	2400(15)
Armament	2 x 4 MM40 Exocet SSM (8 MM40 Block III), 2 x 8 ESSM SAM (VLS, 16 RIM-162), 1 x 21 RAM SAM (21 RIM-116 Block 1B), 1 x 1 - 76/62 OTO-Melara Compact SR, 2 x 1 - 27/63 MLG27, 1 helicopter (AS-565 Panther)
Electronic equipment	Sea Giraffe AMB-3D, NA-25/XM, Scanter 2001 radars, Vigy-EOMS NG e/o system, ELAC 3070NDC Vanguard sonar, SLR-736E Seal, Altesse ZS-3035 ECM suites, MLWS-310, DHY319 laser countermeasures systems, 2x MASS decoy RL, 2x WASS C310 torpedo decoy RL, IPN-S CCS
Complement	37 + 8 passengers

Standard scale images

Graphics

Project history

Combattante BR71 design. Programme LEWA-1. 4 ships were ordered in 2003, two more in 2005. Steel hull with aluminium superstructure. ESSM launchers are arranged aside of helicopter hangar. Originally planned 30mm Marlin guns were replaced in final design by 27mm Mauser guns. There is reserved place for mine avoidance sonar, mine countermeasures drones and mine rails.

Modernizations

None.

Naval service

No significant events.
