Mitú 2000

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
LR181 Tenerife, 2007- PRF305 LR182 Tarapaca, 2007- PRF306 LR183 Mompox, 2007- PRF307 LR184 Orocue, 2007- PRF308 LR185 Calamar, 2007- PRF309 LR186 Manangué, 2007- PRF310 LR187 Monclart, 2007- PRF311 LR188 Caucaya, 2007- PRF312 LR189 Mitú, 2007- PRF313	Bender SB, Mobile, USA: LR181-189	1993: LR181-189	none	none	in service (2019): PRF305-313

Technical data

Displacement standard, t
Displacement full, t	20
Length, m	12.4
Breadth, m	2.89
Draught, m	0.61
No of shafts	2
Machinery	2 Caterpillar 3208TA diesels
Power, h. p.	850
Max speed, kts	29
Fuel, t	diesel oil 2
Endurance, nm(kts)	530(15)
Armament	1 x 2 - 12.7/90, 2 x 1 - 12.7/90, 2 x 1 - 7.6/90, 1 x 1 - 40/19 Mk 19 grenade launcher
Electronic equipment	Raytheon 1900 radar
Complement	5 + 12 troops

Graphics

Project history

US 40ft patrol design, intended for antidrug trade patrol on rivers. Aluminium construction. Can be transported in a C-130 cargo plane. Propellers are in the tunnels.

Modernizations

None.

Naval service

No significant events.
