P463 patrol boats (1987-1988)
1995
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
P463 P464 P465, late 1990s- P440, 2013- 46 P466, late 1990s- P441, 2013- 47 P467, late 1990s- P442, 2013- 48 P468, late 1990s- P443, 2013- 49 |
Israeli Aircraft Industries, Be'er Sheva, Israel: P463-468 |
1987: P463-466 1988: P467, 468 |
P463 (Tamil Tigers 29.8.1995), P464 (Tamil Tigers 29.8.1993) |
None | in service (2019): 46-49 |
Technical data
| Displacement standard, t | 48 |
|---|---|
| Displacement full, t | 54 |
| Length, m | 22.4 |
| Breadth, m | 5.50 |
| Draught, m | 1.80 |
| No of shafts | 2 |
| Machinery | 2 MTU 12V396 TB93 diesels |
| Power, h. p. | 3260 |
| Max speed, kts | 46 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1200(17) |
| Armament | 2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90 |
| Electronic equipment | Decca 926 radar |
| Complement | 12 |
Standard scale images
similar P451 1985
Graphics
1995
Project history
Israeli 'Super Dvora Mk I' class. Aluminium construction.
Modernizations
none.
Naval service
In 2013 all survived boats were transferred to Coast Guard.
