No81

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
№33 [No33], 8.1942- №24 [No24], 11.1942- №81 [No81], 5.1943- №332 [No332], 5.1943- №81 [No81] №43 [No43], 6.1942- №31 [No31], 8.1942- №21 [No21] №44 [No44], 6.1942- №32 [No32], 8.1942- №23 [No23], 5.1943- №331 [No331], 3.1944- БК-331 [BK-331] №45 [No45], 6.1942- №34 [No34], 8.1942- №25 [No25] №53 [No53], 8.1942- №81 [No81], 9.1942- №34 [No34], 10.1942- №26 [No26], 10.1942- №101 [No101], 11.1942- №82 [No82], 5.1943- №334 [No334] №54 [No54], 8.1942- №82 [No82], 9.1942- №101 [No101], 10.1942- №26 [No26], 5.1943- №333 [No333], 3.1944- БК-333 [BK-333] №102 [No102], 11.1942- №83 [No83], 3.1943- №324 [No324], 6.1943- №323 [No323], 3.1944- БК-323 [BK-323]	340 Yd, Zelenodolsk: No33, 43-45, 53, 54, 102	6-10/1942: No33, 43 - 45, 53, 54, 102	No332 (10.11.1943), No21 (8.10.1942), No25 (3.11.1942)	none	1950s: all survived

Technical data

Displacement standard, t	32
Displacement full, t	36.5
Length, m	24.7
Breadth, m	3.85
Draught, m	0.60
No of shafts	2
Machinery	2 V-2 diesels
Power, h. p.	800
Max speed, kts	19
Fuel, t	diesel oil 2.3
Endurance, nm(kts)
Armour, mm	belt: 7, deck: 4, turrets: 45 - 30, CT: 7
Armament	1 x 1 - 76/40 F-34 3 x 1 - 7.6/94
Complement	13

Standard scale images

Graphics

Project history

Diesel-engined armoured MGB for Amu-Darya, designed under guidance of Yu. Yu. Benua in 1939 on the basis of project 1125, with replacement of the aviation motors by 2 V-2 tank diesels.

Ship protection

Hull and CT had bullet-proof protection, guns placed in standard tank turrets. 76/30mm 8K guns were on open mounts without shields.

Modernizations

None.

Naval service

Survived boats in 1945 were transferred to Board Guard.
