1965

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
H72 Camiguin, 1965- HB77 Camiguin H73 Siquijer, 1965- HB76 Siquijer	CN Rodriguez, Messina, Italy: H72, 73	4/1965: H72, 73	none	none	1979: HB76, 77

Technical data

Displacement standard, t	28
Displacement full, t	36
Length, m	20.7
Breadth, m	4.67 deck 7.35 foils
Draught, m	2.71 hull 1.16 on foils
No of shafts	2
Machinery	2 Mercedes Benz diesels
Power, h. p.	1250
Max speed, kts	38
Fuel, t	diesel oil
Endurance, nm(kts)	400
Armament	1 x 1 - 20/70 Mk 10
Electronic equipment
Complement	15

Graphics

Project history

Hydrofoils for naval and police patrol duties.

Modernizations

None.

Naval service

: No significant events.
