Sánchez Carrión 1971

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Velarde, 1975- Río Vitor	21, 1975- 229		Vosper, Portsmouth, UK		10.7.1964	1965	Coast Guard 1975, deleted 1990
Santillana, 1975- Río Içá	22, 1975- 228		Vosper, Portsmouth, UK		24.4.1964	1965	Coast Guard 1975, deleted 1982
De Los Heros, 1975- Río Chicama	23, 1975- 224		Vosper, Portsmouth, UK		18.11.1964	1965	Coast Guard 1975, deleted 1986
Herrera, 1975- Río Pativilca	24, 1975- 225		Vosper, Portsmouth, UK		26.10.1964	1965	Coast Guard 1975, deleted 1995
Larrea, 1975- Río Huaura	25, 1975- 226		Vosper, Portsmouth, UK		18.2.1965	1965	Coast Guard 1975, deleted 1983
Sánchez Carrión, 1975- Río Locumba	26, 1975- 227		Vosper, Portsmouth, UK		18.2.1965	1965	Coast Guard 1975, deleted 1998

Technical data

Displacement standard, t	100
Displacement full, t	130
Length, m	31.5 wl 33.4 oa
Breadth, m	6.40
Draught, m	1.70
No of shafts	2
Machinery	2 Napier-Deltic T38-37 diesels
Power, h. p.	6200
Max speed, kts	30
Fuel, t	diesel oil
Endurance, nm(kts)	1100(15)
Armament	2 x 1 - 20/70 Mk 7
Electronic equipment	Decca TM707 radar, sonar
Complement	25

Standard scale images

Graphics

Project history

Designed and built as multi-purpose patrol, rescue, fishery protection vessels, able to carry guns, 4 torpedoes in side-launching racks, twin RL (instead of fwd gun), mines or DCs. Never carried full armament.

Modernizations

1975, all: - 2 x 1 - 20/70; + 2 x 1 - 40/60 Mk 3

Naval service

No significant events.
