BALUCHISTAN large patrol craft (1976-1980)
Baluchistan 1978
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| بلوچستان [Baluchistan] | P155 | China | 1976 | stricken 1992 | |||
| سندھ [Sind] | P159 | China | 1976 | stricken 1992 | |||
| سرحد [Sarhad] | P161 | China | 4.1980 | stricken 1992 | |||
| پنجاب [Punjab] | P197 | China | 4.1980 | stricken 1994 |
Technical data
| Displacement standard, t | 395 |
|---|---|
| Displacement full, t | 430 |
| Length, m | 58.8 |
| Breadth, m | 7.20 |
| Draught, m | 2.24 hull |
| No of shafts | 4 |
| Machinery | 4 9D diesels |
| Power, h. p. | 8800 |
| Max speed, kts | 30.5 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1800(14) |
| Armament | 2 x 2 - 57/62 type 66, 2 x 2 - 25/80 type 61M, 4 x 5 type 81 ASWRL, 2 DCT, 2 DCR, mines |
| Electronic equipment | type 351 radar, Tamir-11 sonar |
| Complement | 70 |
Standard scale images
Baluchistan 1980
Graphics
Baluchistan 1978
Project history
Chinese type 037 craft.
Modernizations
None.
Naval service
No significant events.
