José María Palas 1996

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
José María Palas	GC103, 1999- PM103		Swiftships, Morgan City, USA			10.1989	in service (2019)
Medardo Monzón Coronado	GC104, 1999- PM104		Swiftships, Morgan City, USA			4.1990	in service (2019)

Technical data

Displacement standard, t	100
Displacement full, t	130
Length, m	33.5
Breadth, m	7.62
Draught, m	2.13
No of shafts	4
Machinery	4 General Motors 12V71 TI diesels
Power, h. p.	2400
Max speed, kts	24
Fuel, t	diesel oil 25
Endurance, nm(kts)	1800(15)
Armament	1 x 1 - 40/60 Mk 3, 2 x 1 - 12.7/90
Electronic equipment	Furuno FR8100D radar
Complement	19

Graphics

Project history

USN 110ft Commercial Cruiser class.

Modernizations

late 2010s, both: - 1 x 1 - 12.7/90; + 2 x 1 - 7.6/90

Naval service

No significant events.
