NAVYPEDIA


Skrolsvik 2014

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
KA1 Trondernes, 2004- L4510 Trondernes KA2 Hysnes, 2004- L4511 Hysnes KA3 Hellen, 2004- L4512 Hellen KA4 Torås, 2004- L4513 Torås KA5 Møvik, 2004- L4514 Møvik KA11 Skrolsvik, 2004- L4520 Skrolsvik KA12 Kråkenes, 2004- L4521 Kråkenes KA13 Stangnes, 2004- L4522 Strangnes KA14 Kjøkøy, 2004- L4523 Kjøkøy KA15 Mørvika, 2004- L4524 Mørvika KA16 Kopås, 2004- L4525 Kopås KA17 Tangen, 2004- L4526 Tangen KA18 Oddane, 2004- L4527 Oddane KA19 Malmøya, 2004- L4528 Malmøya KA20 Nidaros KA21 Brettingen, 2004- L4529 Brettingen KA22 Løkhaug, 2004- L4530 Løkhaug KA23 Sørviknes, 2004- L4531 Sørviknes KA30 Bjørgvin KA31 Osternes, 2004- L4532 Osternes KA32 Fjell, 2004- L4533 Fjell KA33 Lerøy, 2004- L4534 Lerøy KA43 Torgauten	Dockstavarvet, Docksta, Sweden: KA1-4 Mjellem & Karlsen, Bergen // Westamarin, Alta: KA5, 11-23, 30-33, 43	1996: KA1-4 1997: KA5, 11, 12 1998: KA13-23, 30, 31 1999: KA32, 33, 43	KA30 Bjørgvin (accident 1.2002)	none	2002-2003: KA20, 30, 43 2010: L4529, 4530, 4533, 4534 2013: L4510, 4511, 4523, 4524, 4528 in service (2019): L4512-4514, 4520-4522, 4525-4527, 4531, 4532

Technical data

Displacement standard, t	13
Displacement full, t	20
Length, m	13.0 pp 15.9 oa
Breadth, m	3.80
Draught, m	1.10
No of shafts	2 waterjets
Machinery	2 Volvo-Scania DSI14 diesels
Power, h. p.	1250
Max speed, kts	40
Fuel, t	diesel oil 2.5
Endurance, nm(kts)	250(30)
Armament	1 x 1 - 12.7/90
Military load	20 troops or 2.8t cargo
Electronic equipment	Decca 110 radar
Complement	3

Graphics

Project history

Swedish CB90H design. Bow ramp.

Modernizations

None.

Naval service

No significant events.
