NAVYPEDIA


Stegg 1979

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
1st series P343 Tjeld, 1982- Sel P344 Skarv P345 Teist P346 Jo P347 Lom P348 Stegg, 1982- Hval P349 Hauk, 1982- Laks P350 Falk P357 Ravn, 1982- Knurr P388 Gribb, 1982- Delfin P389 Geir P390 Erle 2nd series P380 Skrei P381 Hai P382 Sel P383 Hval P384 Laks P385 Knurr P386 Delfin P387 Lyr	Westermoens BB, Mandal: P343-350, 357, 380-390	1960: P343-345 1961: P346-350, 357 1962: P388-390 1963: P382 1964: P381, 383, 384 1966: P380, 385-387	None	None	1981: P344-347, 350, 382-385, 389, 390 1984: P386 1991: P381, 388 1992: P343, 348, 349, 357, 380, 387

Technical data

Displacement standard, t	70
Displacement full, t	76
Length, m	23.00 pp 24.5 oa
Breadth, m	7.50
Draught, m	2.10
No of shafts	2
Machinery	2 Napier Deltic diesels
Power, h. p.	6200
Max speed, kts	45
Fuel, t	diesel oil
Endurance, nm(kts)	1600(25)
Armament	as MTB: 1 x 1 - 40/60 Mk 7, 1 x 1 - 20/70 Mk 10, 4 - 533 TT as MGB: 2 x 1 - 40/60 Mk 7, 2 - 533 TT
Electronic equipment	Decca TM909 radar
Complement	22

Standard scale images

Graphics

Project history

Development of Nasty design intended for series production. Wooden hull.

Modernizations

None.

Naval service

No significant events.
