Oaxaca 2007

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Oaxaca	P161		Astimar, Salina Cruz	17.12.2001	11.4.2003	17.2.2005	in service (2019)
Baja California	P162		Astimar, Tampico	13.12.2001	21.5.2003	4.2007	in service (2019)
Bicentenario de la Independencia	P163		Astimar, Salina Cruz	11.4.2003	23.7.2009	1.6.2010	in service (2019)
Centenario de la Revolución	P164		Astimar, Tampico	21.5.2003	23.11.2009	23.11.2010	in service (2019)
Chiapas	P165		Astimar, Salina Cruz	10.2014	18.11.2015	23.11.2016	in service (2019)
Hidalgo	P166		Astimar, Tampico	2015	9.8.2016	23.11.2017	in service (2019)
Jalisco	P167		Astimar, Salina Cruz	2016	2.7.2018	23.11.2018	in service (2019)
Tampico (ex-Estado de México)	P168		Astimar, Tampico	2016	2019	2019	building (2019)

Technical data

Displacement standard, t	1680
Displacement full, t	1840
Length, m	86.0
Breadth, m	10.5
Draught, m	3.57
No of shafts	2
Machinery	2 Caterpillar 3916 V16 diesels
Power, h. p.
Max speed, kts	19
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	P161-164: 1 x 1 - 76/62 OTO-Melara Compact SR, 1 x 1 - 25/80 Breda-Oerlikon KBB Compact, 2 x 1 - 12.7/90, 1 helicopter (Panther or Fennec) P165-168: 1 x 1 - 57/70 Bofors SAK-57 Mk 3, 1 x 1 - 25/80 Breda-Oerlikon KBB Compact, 1 helicopter (Panther or Fennec)
Electronic equipment	P161-164: Scanter 2001, 2x Sperry radars, NA-25 e/o system, SP-21K CCS P165-168: Scanter 6000, 2x Sperry radars, NA-25 e/o system, SP-21K CCS
Complement	59 + 39 passengers

Standard scale images

Graphics

Project history

Enlarged Durango, Durango T-type. Carry a small 11m 50kts launch.

Modernizations

None.

Naval service

No significant events.
