Pedro Sainz de Baranda1950

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Pedro Sainz de Baranda (ex-PCE844)			Pullman Standard Car, Chicago, USA	7.1943	1.12.1943	2.1944 // 1947	discarded 1965
David Porter (ex-PCE847)			Pullman Standard Car, Chicago, USA	8.1943	27.12.1943	3/1944 // 1947	discarded 1965
Virgilio Uribe (ex-PCE868)			Albina, Portland, USA	8.1942	29.1.1943	8.1943 // 12.1947	discarded 1965
Blas Godínez (ex-PCE871)			Albina, Portland, USA	12.1942	10.3.1943	10.1943 // 1947	discarded 1965
Tomás Marín (ex-PCE875)			Albina, Portland, USA	3.1943	27.5.1943	1.1944 // 1947	discarded 1972

Technical data

Displacement standard, t	795
Displacement full, t	903
Length, m	54.9 wl 56.2 oa
Breadth, m	10.1
Draught, m	2.90
No of shafts	2
Machinery	2 diesels
Power, h. p.	2000
Max speed, kts	15.1
Fuel, t	diesel oil 140
Endurance, nm(kts)	8500 (12)
Armament	Pedro Sainz de Baranda, David Porter, Tomás Marín: 1 x 1 - 76/50 Mk 21, 3 x 2 - 40/60 Mk 1, 4 x 1 - 20/70 Mk 10, 4 DCT Virgilio Uribe: 1 x 1 - 76/50 Mk 21, 3 x 2 - 40/60 Mk 1, 4 DCT Blas Godinez: 1 x 1 - 76/50 Mk 21, 3 x 1 - 40/60 Mk 3, 5 x 1 - 20/70 Mk 10, 4 DCT
Electronic equipment	SG or SL radar, QHA sonar
Complement	96

Standard scale images

Graphics

Project history

Former USN PCE class patrol craft, escorts.

Modernizations

None.

Naval service

No significant events.

1950
