NAVYPEDIA


Acapulco 1951

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Salinas, 1926- Acapulco			Polson IW, Toronto, Canada		1917	11.1917 // 1920	stricken 1959
Mazatlán			Polson IW, Toronto, Canada		1917	11.1917 // 1920	stricken 1949
Tampico			Polson IW, Toronto, Canada		1917	11.1917 // 1920	stricken 1949
Vera Cruz			Polson IW, Toronto, Canada		1917	11.1917 // 1920	stricken 1959

Technical data

Displacement normal, t	357
Displacement full, t	486
Length, m	40.5
Breadth, m	7.13
Draught, m	4.08
No of shafts	1
Machinery	1 VTE, 1 boiler
Power, h. p.	557
Max speed, kts	7
Fuel, t	coal 208
Endurance, nm(kts)
Armament	Salinas, Vera Cruz: 1 x 1 - 25/60 Hotchkiss, 1 x 1 - 13.2/76 Mazatlan, Tampico: 1 x 1 - 57/40 Hotchkiss, 2 x 1 - 40/39 2pdr QF Mk II, 2 x 1 - 7.7/94
Complement	26

Standard scale images

Graphics

Project history

Former Canadian armed trawlers built in days of the First World War, bought by Mexico in 1920 and used as patrols.

Modernizations

None.

Naval service

No significant events.
