Al Fateh 1978

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
البدر [Al Badr] (ex-Б-587 [B-587])	311	01207	Admiralty, Leningrad, USSR	12.3.1981	19.6.1981	25.10.1981 // 1.1982	inoperable 1995
الفاتح [Al Fateh] (ex-Б-533 [B-533])	312	01296	Admiralty, Leningrad, USSR	23.12.1975	16.4.1976	8.10.1976 // 12.1976	foundered 1993
الأحد [Al Ahad] (ex-Б-311 [B-311])	313	01297	Admiralty, Leningrad, USSR	26.9.1976	17.2.1977	15.9.1977 // 2.1978	inoperable 1995
المتراجع [Al Mitraqah] (ex-Б-590 [B-590])	314	01206	Admiralty, Leningrad, USSR	5.4.1980	14.7.1980	21.11.1980 // 21981	inoperable 1995
الخيبر [Al Khyber] (ex-Б-588 [B-588])	315	01208	Admiralty, Leningrad, USSR	26.2.1982	11.6.1982	28.9.1982 // 2.1983	inoperable 1995
الحنين [Al Hunayn] (ex-Б-330 [B-330])	316	01298	Admiralty, Leningrad, USSR	5.3.1977	20.5.1977	27.10.1977 // 2.1978	inoperable 1995

Technical data

Displacement standard, t
Displacement normal, t	1952 / 2475
Length, m	91.3
Breadth, m	7.50
Draught, m	5.09
No of shafts	3
Machinery	3 2D42 diesels / 1 PG-102 + 2 PG-101 electric motors
Power, h. p.	5700 / 5400 (2700 + 2x1350)
Max speed, kts	16.8 / 16
Fuel, t	diesel oil
Endurance, nm(kts)	30000(8.1) / 400(2)
Armament	6 - 533 TT (bow, 12), 4 - 400 TT (stern, 10)
Electronic equipment	Flag radar, MG-200 Arktika-M, Tuloma, MG-10M Kola-M, Svet-M sonars, Nakat ECM suite
Complement	77
Diving depth operational, m	250

Standard scale images

Graphics

Project history

Soviet export project I641K submarines, built for service in tropics.

Modernizations

None.

Naval service

Al Fateh foundered moored in harbour in 1993 and was never repaired.
