Capitán de Fragata David Eyama Angue Osa 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Capitán de Fragata David Eyama Angue Osa	106		Hangchang, Linhai, China // Ukraine	1.8.2008		31.5.2009	in service (2020)

Technical data

Displacement standard, t	1400
Displacement full, t	4000
Length, m	78.7 pp 91.5 oa
Breadth, m	14.7
Draught, m	3.70
No of shafts	2
Machinery	2 Caterpillar 3516HD diesels
Power, h. p.	4580
Max speed, kts
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	1 x 1 - 76/59 AK-176, 2 x (2 Baryer ATGM + 1 - 30/100 + 1 - 7.6/90) Katran-M (8 Baryer), 2 x 2 - 25/82 2M-3M, 2 x 17 - 140 BM-14-17 RL, 1 helicopter
Military load
Electronic equipment	Delta-M, nav. radars
Complement

Graphics

Project history

Ordered in 2007 and laid down as false merchant ro-ro vessel Salamandra. Outfitted and armed in Ukraine.

Modernizations

None.

Naval service

No significant events.
