NAVYPEDIA


No 783 2004

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
207, 1985- 781 208, 1985- 783 209, 1985- 785 210, 1985- 787 211, 1985- 789 212, 1985- 791	Alexandria NY // Vosper Thornycroft, Portchester, UK: 207-212	1980: 207-210 1981: 211 1982: 212	none	none	1989: 785, 791 in service (2019): 781, 783, 787, 789

Technical data

Displacement standard, t	71
Displacement full, t	82
Length, m	25.3
Breadth, m	6.00
Draught, m	1.80
No of shafts	4
Machinery	4 CRM 18V12D/55YE diesels
Power, h. p.	5400
Max speed, kts	40
Fuel, t	diesel oil
Endurance, nm(kts)	400(30)
Armament	2 x 1 Otomat Mk 1 SSM (2 Otomat), 2 x 2 - 30/75 GCM-A01
Electronic equipment	S810, ST802 radars, Cutlass, Matilda ECM suites, 2x Protean decoy RL
Complement	20

Standard scale images

Graphics

Project history

Launched in 1975-1976 at Alexandria with Soviet project 183R wooden hulls and Italian machinery. Weapons and electronics were installed in 1979-1981 by Vosper-Thornycroft. No212 was lost overboard during delivery 16/121980, salvaged and returned to the UK 30.6.1981, and completed repairs 13.8.1982.

Modernizations

1994, all survived: - Cutlass ECM suite; + Triton ECM suite

2007, all survived: - 2 x 1 Otomat Mk 1 SSM; + 2 x 1 Otomat Mk 2 SSM (2 Otomat Mk 2)

Naval service

No significant events.
