GHANTUT corvettes (2013)
Ghantut 2013
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| غنتوت [Ghantut] | P251 | Fincantieri, Muggiano, Italy | 15.2.2011 | 19.1.2012 | 8.1.2013 | in service (2020) | |
| صلاله [Salalah] | P252 | Fincantieri, Muggiano, Italy | 15.2.2011 | 8.6.2012 | 22.4.2013 | in service (2020) |
Technical data
| Displacement standard, t | 520 |
|---|---|
| Displacement full, t | 650 |
| Length, m | 55.8 |
| Breadth, m | 8.80 |
| Draught, m | 2.80 |
| No of shafts | 2 |
| Machinery | 2 MTU 16V4000 M90 diesels |
| Power, h. p. | 7400 |
| Max speed, kts | 20 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1200(14) |
| Armament | 2 x 4 MM40 Exocet SSM (8 MM40 Block III), 2 x 8 VL MICA SAM (VLS, 16 VL MICA), 1 x 1 - 76/62 OTO-Melara Compact SR, 2 x 1 - 12.7/90 |
| Electronic equipment | Kronos 3D, Orion RTN-30X, SIR-M radars, Medusa Mk 4B, NA-30S e/o systems, SEAL ECM suite, 2x MASS decoy RL, IPN-S CCS |
| Complement | 29 |
Standard scale images
Ghantut 2015
Graphics
Ghantut 2013
Project history
Falaj-2 class, ordered in 2010 with an option for building of two more ships by ADSB.
Modernizations
None.
Naval service
No significant events.
