R34 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
MR26 (ex-R26)		850	Schlichting-Werft, Travemünde, Germany			8.1938 // 12.1945	stricken 1948
MR32 (ex-R32)		3236	Abeking & Rasmussen, Lemwerder, Germany			10.1938 // 12.1945	stricken 1947

Technical data

Displacement standard, t	110
Displacement full, t	126
Length, m	35.4
Breadth, m	5.55
Draught, m	1.40 normal 1.42 deep load
No of shafts	2
Machinery	2 MWM diesels
Power, h. p.	1800
Max speed, kts	23.5
Fuel, t	diesel oil 10
Armament	1 x 1 - 37/83 SK C/30, 2 x 2 - 20/65 C/38, 2 x 1 - 20/65 C/38, DCR, 10 mines, mechanical minesweeping gear
Complement	20

Standard scale images

Graphics

Project history

Former German R25 class R-boats, received from Allies.

Modernizations

None.

Naval service

No significant events.
