No5200 fast attack craft (torpedo) (1956-1966)







Ships


Names Builders Commissioned Losses Transfers Discarding

80 boats (5200-... series)

Hudong SY, Shanghai

Chuangxin SY

1956-1966: 80 boats

none

North Vietnam, 1967: 6 boats

1990s: all

1995: ~10 were in service



Technical data


Displacement standard, t

57

Displacement full, t

67

Length, m

25.5

Breadth, m

6.18

Draught, m

1.24

No of shafts

4

Machinery

4 M-50F diesels

Power, h. p.

4800

Max speed, kts

43

Fuel, t

diesel oil

Endurance, nm(kts)

1000(14)

Armament

2 x 2 - 25/112 2M-3M, 2 x 1 - 533 TT or 18 mines, 8 DC

Electronic equipment

Zarnitsa radar

Complement

14



Standard scale images


1980
1980


Graphics





Project history

Chinese-built copy of Soviet Project 183.

Modernizations

None.

Naval service

No significant events.

Ivan Gogin, 2015
