NO511 patrol boats (project 1400ME) (1980-1981)
No532 2008
Ships
| Names | Builders | Completed | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
511-513 515 521-523 531-533 |
More, Feodosiya, USSR: 511-513, 515, 521-523, 531-533 |
1980-1981: 511-513, 515, 521-523, 531-533 |
none |
none |
2002: 515 2005: 531 2010: 513 2012: 511 in service (2019): 512, 521-523, 532, 533 |
Technical data
| Displacement standard, t | 37 |
|---|---|
| Displacement full, t | 40 |
| Length, m | 23.8 |
| Breadth, m | 5.15 |
| Draught, m | 1.00 |
| No of shafts | 2 |
| Machinery | 2 M-401BT diesels |
| Power, h. p. | 2000 |
| Max speed, kts | 29 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 450(13) |
| Armament | 2 x 2 - 12.7/79 |
| Electronic equipment | Lotsiya or Liman radar |
| Complement | 9 |
Standard scale images
No511 1985
Graphics
No532 2008
Project history
Soviet project 1400ME boats, built specially for Bulgaria.
Modernizations
2000s, No521, No533: - 1 x 2 - 12.7/79
Naval service
No significant events.
