1978

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
12 boats: (No11, later No301 and 11 others)	831 Yd, Feodosiya, USSR: 12 boats	1951-1955 // 1957: 12 boats	none	none	early 1970s: 4 boats late 1970s: 4 boats early 1980s: 4 boats

Technical data

Displacement standard, t	19
Displacement full, t	23
Length, m	19.3
Breadth, m	3.43
Draught, m	0.77
No of shafts	2
Machinery	2 M-50-2 diesels
Power, h. p.	2000
Max speed, kts	50
Fuel, t	diesel oil
Endurance, nm(kts)	450(35)
Armament	1 x 2 - 14.5/93, 2 x 1 - 450 TT, 6 DC
Electronic equipment	Zarnitsa radar
Complement	7

Standard scale images

Graphics

Project history

Former Soviet Project 123K MTBs.

Modernizations

None.

Naval service

No significant events.
