NAVYPEDIA


Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
	150, later- P121		China			1974	non-operational late 1990s
	151, later- P122		China			1974	non-operational late 1990s
	152, later- P123, later- P115		China			1974	non-operational late 2010s
	650, later- P931, later- P421		China			1974	non-operational late 1990s
	651, later- P932, later- P422		China			1975	non-operational late 1990s
	652, later- P933, later- P423		China			1975	non-operational late 1990s

Technical data

Displacement standard, t	123
Displacement full, t	135
Length, m	38.8
Breadth, m	5.41
Draught, m	1.55 propellers
No of shafts	4
Machinery	2 M-50F-4 diesels + 2 12D6 diesels
Power, h. p.	4200 (2x1200+2x910)
Max speed, kts	28.5
Fuel, t	diesel oil
Endurance, nm(kts)	750(16.5)
Armament	2 x 2 - 37/63 type 61, 2 x 2 - 25/80 type 61M
Electronic equipment	type 351 radar
Complement	36

Standard scale images

Graphics

Project history

Chinese project 062 patrol boats ('Shanghai II'), transferred without ASW armament.

Modernizations

1990s, all: + 2 - 533 TT

Naval service

P123 defected to Italy in March 1997 but was returned at the end of the year.
