"Huckins 72-ft" torpedo boat (PT69) (1941)
PT69 1941
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
PT69, 9.1941- YP106 |
Huckins Yacht, Jacksonville: PT69 |
6/1941: PT69 |
none |
none |
~1945?: YP106 |
Technical data
| Displacement standard, t | 32 |
|---|---|
| Displacement full, t | 40 |
| Length, m | 21.9 |
| Breadth, m | 6.07 |
| Draught, m |
|
| No of shafts | 3 |
| Machinery | 3 petrol engines |
| Power, h. p. | 3600 |
| Max speed, kts | 42 |
| Fuel, t | petrol |
| Endurance, nm(kts) |
|
| Armament | 2 - 533 TT |
| Complement | 17 |
Graphics
PT69 1941
Project history
Prototype MTB, 72ft Huckins type.
Modernizations
1941, YP106: - 2 - 533 TT; + 2 x 1 - 12.7/90, DC.
Naval service
: MTB was reclassified as patrol craft in 1941, date of discarding is unknown.
© Ivan Gogin, 2014
