DAMRONG RACHANUPHAT patrol craft (1969-1972)





Lopburi Rames 2003

Ships


Name No Yard No Builder Laid down Launched Comp Fate
ดำรงราชานุภาพ [Damrong Rachanuphat] 1802   Schiffwerft Hameln, West Germany     3.1.1969 in service (2019)
ลพบุรีรามาส [Lopburi Ramas] 1803   Schiffwerft Hameln, West Germany     10.12.1972 in service (2019)


Technical data


Displacement standard, t
Displacement full, t430
Length, m56.7
Breadth, m8.10
Draught, m2.40
No of shafts2
Machinery4 MTU diesels
Power, h. p.4400
Max speed, kts23
Fuel, tdiesel oil
Endurance, nm(kts)
Armament1 x 1 - 40/60 Mk 3, 2 x 1 - 20/70 Mk 10
Electronic equipmentDecca 1226, nav. radars
Complement45


Graphics


<i>Lopburi Rames </i>2003
Lopburi Rames 2003


Project history

Large patrol craft.

Modernizations

1990s, new armament consisted of: 1 x 2 - 30/75 GCM-A03, 2 x 1 - 20/90 GAM-B01

Naval service

No significant events.
