NAVYPEDIA


Saettia

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Saettia	CP901		Fincantieri, Muggiano	6.1984	12.1984	20.7.1999	in service (2019)

Technical data

Displacement standard, t	360
Displacement full, t	400
Length, m	47.2 pp 51.7 oa
Breadth, m	8.10
Draught, m	2.50
No of shafts	4
Machinery	4 MTU 16V538TB93 diesels
Power, h. p.	17600
Max speed, kts	38
Fuel, t	diesel oil
Endurance, nm(kts)	2400(16)
Armament	none
Electronic equipment	SPN-753XS(v)2 radar
Complement	33

Standard scale images

Graphics

Project history

Built as a demonstrator for Fincantieri's DA-360T-design guided-missile patrol craft and never acquired by the Italian or any foreign navy despite attempts to sell her. Laid up since the early 1990s, she was acquired by the coast guard and modified by the builder, delivered 20.7.1999. The original armament of one 76mm OTO-Melara Compact gun, a twin 40mm/70 Dardo AA mount, and four Otomat SSMs has been removed, along with the associated fire-control radars. A modified mast was fitted during 2000 and the gun during 2001. Based at Messina. Can carry towed sonar or Achille M-4 submarine drone.

Modernizations

2001: + 1 x 1 - 25/87 KBA25/80

Naval service

No significant events.
