pr. 123K fast attack craft (torpedo) (1951-1955/1970)





1974

Ships


Names Builders Commissioned Losses Transfers Discarding

6 boats

USSR: 6 boats

1951-1955 // 1970: 6 boats

1 boat (10/1973), 1 boat (10/1973)

none

1983: 4 boats



Technical data


Displacement standard, t

19

Displacement full, t

23

Length, m

19.3

Breadth, m

3.43

Draught, m

0.77

No of shafts

2

Machinery

2 M-50-2 diesels

Power, h. p.

2000

Max speed, kts

50

Fuel, t

diesel oil

Endurance, nm(kts)

450(35)

Armament

1 x 2 - 14.5/93, 2 x 1 - 450 TT, 6 DC

Electronic equipment

Zarnitsa radar

Complement

7



Standard scale images


1970
1970
1980
1980


Graphics


1974
1974


Project history

Former Soviet Project 123K MTBs, transferred by Syria.

Modernizations

early 1970s, 4 survived: + 1 x 8 - 82 BM-8-48 RL

Naval service

No significant events.
