Borac Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Морнар [Mornar]	ПБР551 [PBR551]	346	Tito SYd, Kraljevica	1957	1958	9.1959	deleted 1992
Борац [Borac]	ПБР552 [PBR552]	347	Tito SYd, Kraljevica	1964	1965	1965	deleted 1992

Technical data

Displacement standard, t	330
Displacement full, t	430
Length, m	51.8 pp 53.3 oa
Breadth, m	7.00
Draught, m	2.00
No of shafts	2
Machinery	4 SEMT-Pielstick diesels
Power, h. p.	3240
Max speed, kts	24
Fuel, t	diesel oil 55
Endurance, nm(kts)	3000(12)
Armament	2 x 1 - 76/50 Mk 22, 2 x 1 - 40/60 Mk 3, 2 x 1 - 20/70 Mk 10, 1 x 24 - 178 Hedgehog Mk 11 ASWRL, 2 DCT, 2 DCR
Electronic equipment	Decca 45 radar, DUBA-2 sonar
Complement	60

Standard scale images

Graphics

Project history

Improved Le Fougueux with increased armament.

Modernizations

1970-1973, both: - 1 x 1 - 76/50, 2 x 1 - 20/70, 1 x 24 - 178 Hedgehog ASWRL, DUBA-2 sonar; + 1 x 3 - 20/80 M55, 4 x 5 RBU-1200 ASWRL, Tamir-11 sonar

Naval service

No significant events.
