NAVYPEDIA


2002

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
(ex-MT-303)	201	875	Sredne-Nevskiy SSZ, Pontonnyy, USSR			2.1991	in service (2020)

Technical data

Displacement standard, t	750
Displacement full, t	804
Length, m	61.0
Breadth, m	10.2
Draught, m	2.30
No of shafts	2
Machinery	2 M-503B-37 diesels
Power, h. p.	5000
Max speed, kts	16
Fuel, t	diesel oil
Endurance, nm(kts)	3000(12)
Armament	2 x 1 Igla-1 SAM (20 9M313), 2 x 6 - 30/54 AK-306, 2 x 2 - 25/112 2M-3M, 2 x 5 RBU-1200M Uragan ASWRL, 2 DCR (32) or 8 UDE mines, GKT mechanical, TEM-3 magnetic, AT-2 acoustic minesweeping gear, ShZ-1 or ShZ-2 mine clearance line charges
Electronic equipment	MR-212 Vaygach radar, MG-69 Lan', MG-79 Mezen' or MG-89 sonars
Complement	69

Standard scale images

Graphics

Project history

Ocean minesweeper of Soviet export project 266ME.

Modernizations

None.

Naval service

No significant events.
