P1022 2007

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
	P1022		Austal Ships, Henderson, Australia			6.2004	in service (2020)
	P1023		Austal Ships, Henderson, Australia			6.2004	in service (2020)
	P1024		Austal Ships, Henderson, Australia			6.2004	in service (2020)
	P1025		Austal Ships, Henderson, Australia			6.2004	in service (2020)
	P1026		Austal Ships, Henderson, Australia			8.2004	in service (2020)
	P1027		Austal Ships, Henderson, Australia			8.2004	in service (2020)
	P1028		Austal Ships, Henderson, Australia			10.2004	in service (2020)
	P1029		Austal Ships, Henderson, Australia			10.2004	in service (2020)
	P1030		Austal Ships, Henderson, Australia			12.2004	in service (2020)
	P1031		Austal Ships, Henderson, Australia			12.2004	in service (2020)

Technical data

Displacement standard, t	90
Displacement full, t	120
Length, m	32.4 wl 37.5 oa
Breadth, m	7.20
Draught, m	2.20
No of shafts	2
Machinery	2 Caterpillar 3512 diesels
Power, h. p.	3550
Max speed, kts	29
Fuel, t	diesel oil 22
Endurance, nm(kts)	2000(12)
Armament	1 x 2 - 25/82 2M-3M, 2 x 1 - 12.7/79
Electronic equipment	radar
Complement	19

Graphics

Project history

Intended for coastal patrols around the Gulf of Aden and surrounding waterways. A simplified version of an Australian Customs design. Fitted with an articulated crane aft for launch and recovery of a small RIB.

Modernizations

None.

Naval service

No significant events.
