NAVYPEDIA


HQ-512 1995

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
HQ-511 (ex-СДК-71 [SDK-71])	511	771A/28	Stocznia Północna, Gdańsk, Poland	18.5.1969	15.11.1969	25.3.1970 // 16.5.1979	in service (2019)
HQ-512 (ex-СДК-112 [SDK-112])	512	771A/25	Stocznia Północna, Gdańsk, Poland	4.11.1968	28.6.1969	31.10.1969 // 4.1.1980	in service (2019)
HQ-513 (ex-СДК-74 [SDK-74])	513	771A/30	Stocznia Północna, Gdańsk, Poland	11.7.1969	31.1.1970	30.5.1970 // 15.4.1980	in service (2019)

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate HQ-511 (ex-СДК-71 [SDK-71]) 511 771A/28 Stocznia Północna, Gdańsk, Poland 18.5.1969 15.11.1969 25.3.1970 // 16.5.1979 in service (2019) HQ-512 (ex-СДК-112 [SDK-112]) 512 771A/25 Stocznia Północna, Gdańsk, Poland 4.11.1968 28.6.1969 31.10.1969 // 4.1.1980 in service (2019) HQ-513 (ex-СДК-74 [SDK-74]) 513 771A/30 Stocznia Północna, Gdańsk, Poland 11.7.1969 31.1.1970 30.5.1970 // 15.4.1980 in service (2019)

Technical data

Displacement standard, t	805
Displacement full, t	857
Length, m	75.2
Breadth, m	9.02
Draught, m	2.07
No of shafts	2
Machinery	2 40DM diesels
Power, h. p.	4400
Max speed, kts	18.4
Fuel, t	diesel oil
Endurance, nm(kts)	2000(16)
Armament	2 x 2 - 30/71 AK-230, 2 x 18 - 140 WM-18 RL
Military load	6 medium tanks or 10 trucks, 204 troops
Electronic equipment	Donets-2, MR-104 Rys' radars
Complement	37

Standard scale images

Graphics

Project history

Former Soviet project 771A medium landing ships, transferred after service under Soviet flag.

Modernizations

None.

Naval service

No significant events.
