PSKR-108 1998

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
ПСКР-103 [PSKR-103] (ex-ПСКР-103 [PSKR-103])	024	904	More, Feodosia		1983	23.10.1983 // 6.1992	stricken 1996
ПСКР-105 [PSKR-105] (ex-ПСКР-105 [PSKR-105])	025, 1999- BG54	906	More, Feodosia			1985 // 6.1992	stricken 2000
ПСКР-108 [PSKR-108] (ex-ПСКР-108 [PSKR-108])	026, 1999- BG53	909	More, Feodosia			19.9.1990 // 6.1992	stricken 2000
ПСКР-115 [PSKR-115] (ex-ПСКР-115 [PSKR-115]), 8.1995- Галичина [Galichina]	027, 1999- BG55	912	More, Feodosia	16.10.1989		10.7.1993	stricken 2008

Technical data

Displacement standard, t	190
Displacement full, t	221
Length, m	40.2
Breadth, m	8.00 wl 15.9 max
Draught, m	1.58 hull 4.90 max
No of shafts	2
Machinery	2 M-70 gas turbines
Power, h. p.	20000
Max speed, kts	61
Fuel, t	gas turbine oil
Endurance, nm(kts)	410(51)
Armament	1 x 1 - 76/59 AK-176, 1 x 6 - 30/54 AK-630, 2 - 400 TT, 1 x 7 - 55 MRG-1 Ogonyok grenade launcher, 1 DCR (6)
Electronic equipment	Rangout or MR-220 Reyd, MR-123 Vympel-A radars, Ros'-K sonar
Complement	24

Standard scale images

Graphics

Project history

Border Guard, later Coast Guard. Former project 133 hydrofoils of Soviet Border Guard, last ship was completed for Ukraine.

Modernizations

None.

Naval service

No significant events.
