Lubny 2009

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
171 Лубни [Lubny] (ex-AK-211), 1999- BG82 Лубни [Lubny] 172 Нiжин [Nizhyn] (ex-AK-563), 1999- BG83 Нiжин [Nizhyn] 173 Канiв [Kaniv] (ex-AK-246), 1999- BG81 Канiв [Kaniv] 174 Iзмаïл [Izmayil] (ex-AK-397), 1999- BG84 Iзмаïл [Izmayil]	Zaliv, Kerch': 171-174	1968 // 1994: 172 1969 // 1994: 174 1971 // 1994: 173 1972 // 1994: 171	none	none	in service (2020): BG81-84

Technical data

Displacement standard, t
Displacement full, t	71 77
Length, m	27.4
Breadth, m	4.32
Draught, m	0.85 1.00
No of shafts	2
Machinery	2 M-50F diesels
Power, h. p.	2400
Max speed, kts	24
Fuel, t	diesel oil
Endurance, nm(kts)	320(10)
Armour, mm	belt: 8, deck: 4, turret: 15 - 10, CT: 10 - 4
Armament	171, 173: 1 x 1 - 76/48 D-56TS, 1 x 2 - 25/82 2M-3M, 1 x 1 - 7.6/94, 1 x 17 - 140 BM-14-17 RL, 4 x 1 - 30 BP-30 Plamia GL, 10 mines 172, 174: 1 x 1 - 76/48 D-56TS, 1 x 2 - 14.5/93, 1 x 1 - 7.6/94, 10 mines
Electronic equipment	Donets-2 radar
Complement	14

Standard scale images

Graphics

Project history

Border Guard, later Coast Guard. Former project 1204 riverine armoured gunboats of Soviet Navy.

Modernizations

None.

Naval service

No significant events.
