NAVYPEDIA


Nikopol' 2018

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
U174 Аккерман [Akkerman], 2018- P174 Аккерман [Akkerman] U175 Бердянськ {Berdyansk], 2018- P175 Бердянськ [Berdyansk] P176 Нiкополь [Nikopol'] P177 Кременчук [Kremenchuk] P178 Лубни [Lubny] P179 Вишгород [Vyshgorod] P180 Костопiль [Kostopil'] P181 P182	Kuznya na Rybalskomu, Kiev: U174, 175, P176-182	2016: U174, 175 2018: P176-179 2020: P180 2021: P181 2022: P182	none	none	in service (2020): P174-179 building (2020): P180-182

Technical data

Displacement standard, t
Displacement full, t	51
Length, m	23.0
Breadth, m	4.80
Draught, m	1.00
No of shafts	2 waterjets
Machinery	2 M-401B diesels
Power, h. p.	2000
Max speed, kts	25
Fuel, t	diesel oil
Endurance, nm(kts)	700(12)
Armament	2 x (2 x Baryer ATGM + 1 - 30/80 + 1 x 1 - 7.6/90 + 1 x 1 - 30/17 grenade launcher) Katran-M modules (4 Baryer)
Electronic equipment	Delta-M, Furuno radars, Sarmat e/o system
Complement	6

Graphics

Project history

Domestic project 58155, intended for riverine and inshore service. Bridge and engine room have local bullet-proof protection.

Modernizations

None.

Naval service

Berdyansk and Nikopol' were captured by ships and aircraft of Russian Border Guard during an attempt to illegitimate break through the Kerch' Strait but 18.11.2019 returned by Russia to Ukrainian Navy.
