Woodcock

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Woodcock		326	Thornycroft, Chiswick / Shanghai, China		1897 // 8.4.1898	1898	sold 3.1923
Woodlark	N0C	327	Thornycroft, Chiswick / Shanghai, China		1897 // 8.4.1898	1898	sold 7.1923

Technical data

Displacement normal, t	150
Displacement full, t
Length, m	44.2
Breadth, m	7.30
Draught, m	0.60
No of shafts	1
Machinery	1 steam engine
Power, h. p.	550
Max speed, kts	13
Fuel, t	coal 28
Endurance, nm(kts)
Armament	2 x 1 - 57/40 6pdr Hotchkiss Mk I, 4 x 1 - 7.7/94
Complement	25

Graphics

Project history

Tunnel-screw type, hull had bullet-proof protection.

Modernizations

None

Naval service

Paid off in December 1914 but were re-commissioned post-war.

Many thanks to Wolfgang Stöhr for additional information on this page.
