Medina 1882

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Medina		332	Palmers, Jarrow	1875	3.8.1876	1876	sold 1904
Medway		333	Palmers, Jarrow	1875	3.10.1876	1876	sold 1904
Sabrina		334	Palmers, Jarrow	1875	3.10.1876	1876	diving tender Sabine 1916
Spey		335	Palmers, Jarrow	1875	5.10.1876	1876	deleted 1915
Tay		336	Palmers, Jarrow	1875	19.10.1876	1876	sold 10.1920
Tees		337	Palmers, Jarrow	1875	19.10.1876	1876	sold 7.1907
Dee		341	Palmers, Jarrow	1876	4.4.1877	1877	torpedo instruction vessel 1892, sold 7.1902
Don		342	Palmers, Jarrow	1876	14.4.1877	1877	concrete barge 1906, gunboat 1908, lighter 1911
Esk		343	Palmers, Jarrow	1876	28.4.1877	1877	sold 4.1903
Slaney		344	Palmers, Jarrow	1876	28.4.1877	1877	diving tender 1906
Trent		345	Palmers, Jarrow	1876	23.8.1877	1877	diving tender Pembroke 9.1905
Tweed		346	Palmers, Jarrow	1876	23.8.1877	1877	sold 11.1905

Technical data

Displacement normal, t	363
Displacement full, t
Length, m	33.5
Breadth, m	10.4
Draught, m	1.70 - 1.75
No of shafts	2
Machinery	sails + 2 2-cyl HSE, 1 cylindrical boiler
Power, h. p.	310
Max speed, kts	9.5
Fuel, t	coal
Endurance, nm(kts)
Armament	3 x 1 - 160/16 64pdr 64cwt MLR
Complement	51

Graphics

Project history Rendel 'flatiron' gunboats with medium-calibre guns. Modernizations

Rendel 'flatiron' gunboats with medium-calibre guns. Modernizations: None.

Naval service

No significant events.
