ACHERON destroyers (29, 1910 - 1916)





Huon

Ships


Name No Yard No Builder Laid down Launched Comp Fate Modification
Ferret H35, H32, F93   White, Cowes 9.1910 12.4.1911 10.1911 sold 5.1921 Admiralty design
Forester H39, H34   White, Cowes 9.1910 1.6.1911 1.1912 sold 11.121 Admiralty design
Sandfly H87, H99, F95   Swan Hunter, Wallsend 8.1910 26.7.1911 12.1911 sold 5.1921 Admiralty design
Hind H47, H40   John Brown, Clydebank 2.1911 28.7.1911 11.1911 sold 5.1921 Admiralty design
Lapwing H56, H48   Cammell Laird, Birkenhead 2.1911 29.7.1911 4.1912 BU 10.1921 Admiralty design
Defender H28, H29   Denny, Dumbarton 11.1910 30.8.1911 1.1912 sold 11.1921 Admiralty design
Jackal H55, H44   Hawthorn Leslie, Hebburn 10.1910 9.9.1911 1.1912 BU 9.1920 Admiralty design
Phoenix H75, H94   Vickers, Barrow 1.1911 9.10.1911 5.1912 sunk 14.5.1918 Admiralty design
Lizard H58, H60   Cammell Laird, Birkenhead 2.1911 10.10.1911 6.1912 sold 11.1921 Admiralty design
Goshawk H45, H37   Beardmore, Dalmuir 1.1911 18.10.1911 5.1912 sold 11.1921 Admiralty design
Druid H33, H30   Denny, Dumbarton 11.1910 4.12.1911 3.1912 sold 5.1921 Admiralty design
Hornet H49, H42   John Brown, Clydebank 1.1911 20.12.1911 3.1912 sold 5.1921 Admiralty design
Tigress H92, H4A   Hawthorn Leslie, Hebburn 2.1911 20.12.1911 3.1912 sold 5.1921 Admiralty design
Hydra H50, H43   John Brown, Clydebank 2.1911 19.2.1912 4.1912 sold 5.1921 Admiralty design
Archer H10, H29, H06   Yarrow, Scotstoun 9.1910 21.10.1911 3.1912 sold 5.1921 Yarrow specials
Attack H14, H86, H08   Yarrow, Scotstoun 9.1910 12.12.1911 5.1912 sunk 30.12.1917 Yarrow specials
Acheron H00, H02   Thornycroft, Woolston 9.1910 26.7.1911 10.1911 sold 5.1921 Thornycroft specials
Ariel H11, H37, H07   Thornycroft, Woolston 10.1910 26.9.1911 3.1912 sunk 2.8.1918 Thornycroft specials
Badger H15, H52, H09   Denny, Dumbarton 10.1910 11.7.1911 8.1912 sold 5.1921 Parsons specials
Beaver H17, H66, H20   Denny, Dumbarton 10.1910 6.10.1911 11.1912 sold 5.1921 Parsons specials
Firedrake H97, H33   Yarrow, Scotstoun 7.1911 9.4.1912 9.1912 BU 10.1921 Yarrow specials, Firedrake group
Lurcher H01, H65   Yarrow, Scotstoun 7/1911 1.6.1912 10/1912 BU 6.1922 Yarrow specials, Firedrake group
Oak H12, H38, H92   Yarrow, Scotstoun 7.1911 5.9.1912 11.1912 BU 5.1921 Yarrow specials, Firedrake group
Parramatta (RAN)     Fairfield, Govan 1909 9.2.1910 8.1910 BU 1929 Australian type
Yarra (RAN)     Denny, Dumbarton 1909 8.4.1910 9.1910 BU 1929 Australian type
Warrego (RAN)     Fairfield, Govan / Cockatoo DYd, Australia 7.1910 4.4.1911 6.1912 hulk 1929 Australian type
Huon (RAN) (ex-Derwent)     Cockatoo DYd, Australia 1.1913 19.12.1914 12.1915 sunk as target 9.4.1930 Australian type
Torrens (RAN)     Cockatoo DYd, Australia 1914 28.8.1915 7.1916 sunk as target 24.11.1930 Australian type
Swan (RAN)     Cockatoo DYd, Australia 1914 11.12.1915 8.1916 BU 9.1929 Australian type


Technical data


Displacement normal, t

778

Displacement full, t

990

Length, m

75.0

Breadth, m

7.80

Draught, m

2.70

No of shafts

3

Machinery

3 Parsons steam turbines, 3 Yarrow boilers

Badger, Beaver: 3 sets Parsons semi-geared steam turbines, 3 Yarrow boilers

Ferret, Forester: 3 Parsons steam turbines, 3 White-Forster boilers

Power, h. p.

13500

Archer, Attack: 16000

Acheron, Ariel: 15500

Firedrake, Lurcher, Oak: 20000

Max speed, kts

27

Archer, Attack: 28

Acheron, Ariel: 29

Firedrake, Lurcher, Oak: 32

Fuel, t

oil 178

Endurance, nm(kts)2300(13)
Armament

2 x 1 - 102/40 BL Mk VIII, 2 x 1 - 76/40 12pdr 12cwt QF Mk I, 2 x 1 - 533 TT

Australian type: 1 x 1 - 102/40 BL Mk VIII, 3 x 1 - 76/40 12pdr 12cwt QF Mk I, 3 x 1 - 450 TT

Complement

70



Standard scale images


<i>Goshawk </i>1912
Goshawk 1912


Graphics


<i>Huon</i>
Huon
<i>Oak</i>
Oak
<i>Jackal</i>
Jackal


Project history

The 20 destroyers in the 1910-11 Programme were to be repeats of the Acorns, but 6 'specials' were included to give the specialist firms a chance to improve performance. To try to match the latest German destroyers Yarrow's were given an order for 3 more, with a free hand to increase length and power. They were very similar to the standard boats but had more rake to the funnels and masts. The layout was identical to the Acorns but had two level-topped funnels. Although the fore funnel was set back from the bridge it was still too short to avoid smoking out the compass platform, and the standard boats had the fore funnel raised from September 1916. The RAN ordered 3 more Yarrow 'specials', but the design was modified by Sir John Biles. They were built by other yards to the modified design, and sections for a fourth was shipped out to Australia for assembly, and two more were built locally. They resembled the standard design but had two raked funnels. All the RN boats were redesignated the 'I' class in October 1913. The design was submitted for approval in May 1910

Modernizations

1917, Ariel, Ferret, Sandfly: were converted to minelayers: - 1 x 1 - 102/40, 1 x 1 - 533 TT; + rails for 40 mines

Naval service

Attack was torpedoed or mined 30.12.1917 by German submarine UC34 off Alexandria, Ariel was stricken by German mine in North sea 2.8.1918, Phoenix was torpedoed by Austro-Hungarian submarine U27 in Adriatic sea 14.5.1918.
