Das 2011

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
موريجب [Murayjib]	CM01, 2001- P6501, 2002- P161		Lürssen, Vegesack, West Germany		3.1989	5/1990	in service (2020)
داس [Das]	CM02, 2001- P6502, 2002- P162		Lürssen, Vegesack, West Germany		5.1989	10/1991	in service (2020)

Technical data

Displacement standard, t	560
Displacement full, t	630
Length, m	62.9 pp 66.0 oa
Breadth, m	9.30
Draught, m	2.90
No of shafts	4
Machinery	4 MTU 16V538 TB92 diesels
Power, h. p.	15600
Max speed, kts	34
Fuel, t	diesel oil 120
Endurance, nm(kts)	4000(16)
Armament	2 x 4 MM40 Exocet SSM (8 MM40 Block II), 1 x 8 Crotale modulaire SAM (8 Crotale), 1 x 1 - 76/62 OTO-Melara Compact SR, 1 x 1 - 30/77 Goalkeeper, helicopter deck
Electronic equipment	Decca TM1226, Sea Giraffe 50HC, 9LV223 Mk 2, Castor IIJ, Goalkeeper radars, Najir e/o system, Cutlass RDL-2, Cygnus ECM suites, 2x Dagaie decoy RL
Complement	43

Standard scale images

Graphics

Project history

Lürssen 'FPB62' type. Specially adapted for conditions of the Gulf, being well armed and air-capable. Ships had helicopter deck able to carry Alouette III helicopter but no hangar.

Modernizations

2006: - Decca TM1226 radar; + Scout radar

2009, Das; 2010, Murayjib: diesels were replaced by 4 MTU 20V538 TB92 (15600hp, 34kts); - 2 x 4 MM40 Exocet Block II SSM; + 2 x 4 MM40 Exocet SSM (8 MM40 Block III), 2 x 1 - 12.7/90

Naval service

No significant events.
