Anafartalar 2001

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Preveze	S353		Gölçuk NSY, Kocaeli, Izmir	27.7.1989	22.10.1993	28.7.1994	in service (2019)
Sakarya	S354		Gölçuk NSY, Kocaeli, Izmir	4.4.1990	28.7.1994	23.9.1995	in service (2019)
18 Mart	S355		Gölçuk NSY, Kocaeli, Izmir	28.7.1994	25.8.1997	24.6.1998	in service (2019)
Anafartalar	S356		Gölçuk NSY, Kocaeli, Izmir	1.8.1995	1.9.1998	22.7.1999	in service (2019)
Gür	S357		Gölçuk NSY, Kocaeli, Izmir	24.7.1998	5.2002	24.7.2003	in service (2019)
Çanakkale	S358		Gölçuk NSY, Kocaeli, Izmir	22.7.1999	23.6.2004	26.7.2005	in service (2019)
Burakreis	S359		Gölçuk NSY, Kocaeli, Izmir	25.7.2001	5.9.2005	15.2.2006	in service (2019)
I. Inönü	S360		Gölçuk NSY, Kocaeli, Izmir	25.7.2002	5.2006	22.7.2007	in service (2019)

Technical data

Displacement standard, t
Displacement normal, t	1454 / 1586
Length, m	62.0
Breadth, m	6.25 hull 7.60 stern planes
Draught, m	5.80
No of shafts	1
Machinery	4 MTU 12V493 AZ80 diesel-generators, 1 Siemens electric motor
Power, h. p.	2400 / 5000
Max speed, kts	11 / 21
Fuel, t	diesel oil
Endurance, nm(kts)	8200(8) / 400(4)
Armament	S353-356: 8 - 533 TT (bow, 14 Mk 24 Mod.2 Tigerfish) S357-360: 8 - 533 TT (bow, 14 DM2A4)
Electronic equipment	S353-356: nav. radar, CSU-83/1 (KAE) sonar suite, TAS-3 sonar, Porpoise ECM suite, ISUS-83/2 CCS S357-360: nav. radar, CSU-83/1 (KAE) sonar suite, TAS-3 sonar, Sealion ECM suite, ISUS-83/2 CCS
Complement	30
Diving depth operational, m	320

Standard scale images

Graphics

Project history

Types 209T1/1400 (first four) and 209T2/1400 (others). Lengthened variant of the standard IKL1400 design.

Modernizations

mid-2010s, all: + ability to launch Sub-Harpoon SSM (up to 4 UGM-84C instead of torpedoes).

Naval service

No significant events.
