ŞAMANDIRA 1 distribution-box minefield tenders (/1959-1994)


Şamandıra 1

Names	Builders	Commissioned	Losses	Transfers	Discarding
Y131 Şamandıra 1, later- Y1148 Şamandıra 1, later- Y81 Şamandıra 1 Y132 Şamandıra 11, later- Y1149 Şamandıra 11, later- Y91 Şamandıra 11 Y1150 Şamandıra 12, later- Y92 Şamandıra 12	USA: Y131, 132, 1150	1950s // 1959: Y131, 132 1950s // 1994: Y1150	None	None	2003: Y81 2006: Y91, 92

Names

Builders

Commissioned

Losses

Transfers

Discarding

Y131 Şamandıra 1, later- Y1148 Şamandıra 1, later- Y81 Şamandıra 1

Y132 Şamandıra 11, later- Y1149 Şamandıra 11, later- Y91 Şamandıra 11

Y1150 Şamandıra 12, later- Y92 Şamandıra 12

USA: Y131, 132, 1150

1950s // 1959: Y131, 132

1950s // 1994: Y1150

None

2003: Y81

2006: Y91, 92

Displacement standard, t
Displacement full, t	72
Length, m	19.6
Breadth, m	5.72
Draught, m	1.83
No of shafts	1
Machinery	1 General Motors Gray Marine 64HN9 diesel
Power, h. p.	225
Max speed, kts	9.5
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	none
Complement	6

Şamandıra 1

Wooden construction. Were used as controlled-minefield electrical distribution box tenders.

None.

No significant events.
