NAVYPEDIA


LSB5 1948

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
LSB1 (ex-ML1124) LSB2 (ex-ML1135) LSB3 (ex-ML1256) LSB4 (ex-ML1296) LSB5 (ex-ML1294) LSB6 (ex-ML1282) LSB7 (ex-ML1245) LSB8 (ex-ML1243)	Sussex SB Co., Shoreham, UK: LSB1, 5 Berthon Boat, Lymington, UK: LSB3 Robinson, Lowestoft, UK: LSB7 Sittingbourne SB Co., UK: LSB6 McGruer, Clynder, UK: LSB4 McLean, Renfrew, UK: LSB8 Thornycroft, Hampton, UK: LSB2	1942 // 3.1943: LSB1, 2 1943 // 8-11/1943: LSB3 - 8	None	None	1960-1962: LSB1 - 8

Technical data

Displacement standard, t	46
Displacement full, t	54
Length, m	22.0
Breadth, m	4.83
Draught, m	1.40 deep load
No of shafts	2
Machinery	LSB5, 7: 2 Gardner diesels LSB4: 2 Glennifer diesels LSB1 - 3, 6, 8: 2 Thornycroft diesels
Power, h. p.	LSB5, 7: 300 LSB4: 320 LSB1 - 3, 6, 8: 260
Max speed, kts	LSB5, 7: 11.8 LSB4: 11.5 LSB1 - 3, 6, 8: 11
Fuel, t	diesel oil 7500 l
Endurance, nm(kts)
Armament	1 x 1 - 47/40 3pdr Hotchkiss Mk I/II or 1 x 1 - 40/50 Mk XIV Rolls-Royce or 1 x 1 - 40/39 2pdr QF Mk VIII, 1 x 1 - 20/70 Oerlikon Mk II/IV, 2 x 2 - 7.7/94, 8 DC
Electronic equipment	type 134 sonar
Complement	10

Standard scale images

Graphics

Project history

Patrol launches transferred to Turkey after service under British flag.

Modernizations

None.

Naval service

No significant events.
