Hibiscus 2009

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
CG11 Scarlet Ibis CG12 Hibiscus CG13 Humming Bird CG14 Chanonia CG15 Poui CG16 Teak	Austal, Henderson, Australia: CG11-16	2009: CG11-13 2010: CG14-16	none	none	in service (2020): CG11-16

Technical data

Displacement standard, t
Displacement full, t	85
Length, m	24.6 pp 30.0 oa
Breadth, m	6.40
Draught, m	1.50
No of shafts	2 waterjets
Machinery	2 MTU 16V2000 M92 diesels
Power, h. p.	4435
Max speed, kts	40
Fuel, t	diesel oil
Endurance, nm(kts)	1000(10)
Armament	1 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90
Electronic equipment	Sperry radar
Complement	11

Graphics

Project history

Aluminium hull, ordered in 2008.

Modernizations

None.
