2003

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
JW9841, 9842 JW9843, 9844, late 2000s- P43, 44	Hudung SY, Shanghai, China: JW9841-9844	1975: JW9841-9844	none	none	1998: JW9841, 9842 in service (2020): P43, 44

Technical data

Displacement standard, t	39
Displacement full, t	46
Length, m	22.5
Breadth, m	3.80
Draught, m	1.15
No of shafts	3
Machinery	3 M-50F-4 diesels
Power, h. p.	3600
Max speed, kts	50
Fuel, t	diesel oil
Endurance, nm(kts)	500(30)
Armament	2 x 2 - 14.5/93, 2 - 533 TT
Electronic equipment	type 756 radar
Complement	11

Standard scale images

Graphics

Project history

Chinese project 026 boats without hydrofoils.

Modernizations

None.

Naval service

No significant events.
