SHUN HU 6 patrol craft (1992)
Shun Hu 6 2008
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|---|
| 巡護六 [Shun Hu 6] | HH No. 6 | Feng-Kuo SB, Kaohsiung | 1992 | in service (2019) |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement full, t | 204 |
| Length, m | 38.1 |
| Breadth, m | 7.00 |
| Draught, m | 2.60 |
| No of shafts | 2 |
| Machinery | 2 MTU 396 TE84 diesels |
| Power, h. p. | 3640 |
| Max speed, kts | 20 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 4000(15) |
| Armament | none |
| Electronic equipment | 2x radars |
| Complement | 15 |
Graphics
Shun Hu 6 2008
Project history
Unarmed patrol craft.
Modernizations
None.
Naval service
No significant events.
