NAVYPEDIA


No38 1998

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate	Modification
-	31		Vympel, Rybinsk, USSR			9.1978	in service (2020)	project 205ER
-	32		Vympel, Rybinsk, USSR			10.1978	in service (2020)	project 205ER
-	33		Vympel, Rybinsk, USSR			10.1979	in service (2020)	project 205ER
-	34		Vympel, Rybinsk, USSR			10.1979	in service (2020)	project 205ER
-	35		Vympel, Rybinsk, USSR			11.1979	in service (2020)	project 205ER
-	36		Almaz, Leningrad, USSR			1965-70 // 11.1979	in service (2020)	project 205U
	37		Almaz, Leningrad, USSR			1965-70 // 8.1982	in service (2020)	project 205U
	38		Almaz, Leningrad, USSR			1965-70 // 9.1982	in service (2020)	project 205U
	39		Almaz, Leningrad, USSR			1965-70 // 5.1984	in service (2020)	project 205U
	40		Almaz, Leningrad, USSR			1965-70 // 5.1984	in service (2020)	project 205U

Technical data

Displacement standard, t	192
Displacement full, t	pr. 205U: 235 pr. 205ER: 243
Length, m	38.6
Breadth, m	7.60
Draught, m	pr. 205U: 1.84 pr. 205ER: 2.00
No of shafts	3
Machinery	3 M-504B diesels
Power, h. p.	15000
Max speed, kts	42
Fuel, t	diesel oil
Endurance, nm(kts)	pr. 205U: 1800(14) pr. 205ER: 1620(15)
Armament	31-38: 4 x 1 P-15U SSM (4 P-15U), 2 x 2 - 30/71 AK-230 39, 40: 4 x 1 P-15U SSM (4 P-15U), 1 x 4 Strela-3M SAM (8 9K36M), 2 x 2 - 30/71 AK-230
Electronic equipment	31-38: MR-101 Rangout, MR-104 Rys' radars 39, 40: MR-101 Rangout, MR-104 Rys' radars, 2x PK-16 decoy RL
Complement	29

Standard scale images

Graphics

Project history

Soviet FACs, boats of project 205ER were built specially for export, project 205U boats were transferred after service under Soviet flag.

Modernizations

1980s, 31-38: + 1 x 4 Strela-3M SAM (8 9K36M), 2x PK-16 decoy RL

Naval service

No significant events.
