NAVYPEDIA


1972

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
-	21		341 Yd, Rybinsk, USSR			1960-66 // 1966	sunk 6.10.1973
	21		341 Yd, Rybinsk, USSR			1960-67 // 1973	in service (2020)
-	22		341 Yd, Rybinsk, USSR			1960-66 // 1966	sunk 6.10.1973
	22		341 Yd, Rybinsk, USSR			1960-67 // 1973	in service (2020)
-	23		341 Yd, Rybinsk, USSR			1960-67 // 1973	in service (2020)
-	24		341 Yd, Rybinsk, USSR			1960-67 // 1973	in service (2020)
-	25		341 Yd, Rybinsk, USSR			1960-67 // 1973	in service (2020)
- (ex-R-268)	26		341 Yd, Rybinsk, USSR			1960-67 // 1973	in service (2020)

Technical data

Displacement standard, t	184
Displacement full, t	226
Length, m	38.6
Breadth, m	7.60
Draught, m	1.84
No of shafts	3
Machinery	3 M-504B diesels
Power, h. p.	15000
Max speed, kts	42
Fuel, t	diesel oil
Endurance, nm(kts)	1800(14)
Armament	4 x 1 P-15/P-15T SSM (4 P-15/P-15T), 2 x 2 - 30/71 AK-230
Electronic equipment	MR-101 Rangout, MR-104 Rys' radars
Complement	28

Standard scale images

Graphics

Project history

Soviet Project 205 FAC.

Modernizations

None.

Naval service

No21 and 22 were sunk 6.10.1973 off Latakia by Israeli FAC Garash. Real operation status of other craft is now doubtful.
