Suraya 1974

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
සුරය [Suraya]	P3140, later- P310		China			2.1972	sunk 13.4.1995
වීරයා [Weeraya]	P3141, later- P311		China			2.1972	in service (2019)
රණකාමී [Ranakami]	P3142, later- P312		China			2.1972	sunk 2000
දක්ෂය [Daksaya]	P3143		China			2.1972	stricken 1983
බලවිත [Balawitha]	P3144		China			1975	stricken 1991
ජගත [Jagatha]	P3145, later- P315		China			30.11.1980	in service (2019)
රක්ෂක [Rakshaka]	P3146, later- P316		China			30.11.1980	damaged 13.4.1995, stricken 1996
අබීත 2 [Abeetha II]	P316		China			8.1998	in service (2019)
එඩිතර 2 [Edithara II]	P317		China			8.1998	in service (2019)
විච්ක්රම 2 [Wickrama II]	P318		China			11.6.2000	in service (2019)

Technical data

Displacement standard, t	122
Displacement full, t	135
Length, m	38.8
Breadth, m	5.40
Draught, m	1.60
No of shafts	4
Machinery	2 M-50F-4 diesels, 2 12D6 diesels
Power, h. p.	4200 (2x1200+2x910)
Max speed, kts	28
Fuel, t	diesel oil
Endurance, nm(kts)	750(16.5)
Armament	P3140-3146: 2 x 2 - 37/63 type 61, 2 x 2 - 14.5/93 P316-318: 2 x 2 - 30/75 GCM-A03, 2 x 2 - 14.5/93
Electronic equipment	P3140-3146: type 351 or type 756 radar P316-318: Furuno 825D, Koden MD3220 Mk 2 radars
Complement	34

Standard scale images

Graphics

Project history

Chinese type 062. Three boats received in 1998-2000 differ by armament.

Modernizations

None.

Naval service

Suraya and Rakshaka were badly damaged by Tamil Tiger insurgents 13.4.1995, Suraya sunk that day and Rakshaka was never repaired. Ranakami was sunk by Tamil Tigers in 2000.
