NAVYPEDIA


41 2013

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
P473, late 1990s- P430, mid-2000s- P270, mid-2000s- P404, 2012- 40 P474, late 1990s- P431, mid-2000s- P271, mid-2000s- P405, 2012- 41 P475, late 1990s- P432, mid-2000s- P272, mid-2000s- P406, 2012- 43	Korea SB, Pusan, South Korea: P473-475	1988: P473-475	none	None	in service (2019): 40, 41, 43

Technical data

Displacement standard, t
Displacement full, t	56
Length, m	23.0
Breadth, m	5.40
Draught, m	1.80
No of shafts	2
Machinery	2 MTU 8V396 TB93 diesels
Power, h. p.	3400
Max speed, kts	40
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90
Electronic equipment	Furuno 1510 radar
Complement	12

Graphics

Project history

South Korean 'Killer' type.

Modernizations

none.

Naval service

In 2012 all boats were transferred to Coast Guard.
