P441 patrol boats (1995-1999)





1999

Ships


Names Builders Commissioned Losses Transfers Discarding

P441, late 1990s- P460

P496, late 1990s- P461

P497, late 1990s- P462

P463-465

Israeli Aircraft Industries, Be'er Sheva, Israel: P441, 463-465, 496, 497

1995: P441

1996: P461, 462

1998: P463

1999: P464, 465

P461 (Tamil Tigers 2006), P463 (Tamil Tigers 7.4.2000)

None

in service (2019): P460, 462, 464, 465



Technical data


Displacement standard, t50
Displacement full, t54
Length, m

24.0

Breadth, m

5.60

Draught, m

1.50

No of shafts

2

Machinery

2 MTU 12V396 TE94 diesels

Power, h. p.

4570

Max speed, kts

50

Fuel, t

diesel oil

Endurance, nm(kts)700(30)
Armament

1 x 2 - 23/87 Typhoon, 1 x 1 - 20/70 Mk 10, 4 x 1 - 12.7/79, 6 x 1 - 7.6/90

Electronic equipment

Koden MD3220 Mk 2 radar, MSIS e/o system

Complement10


Standard scale images


similar <i>P451 </i>1985
similar P451 1985


Graphics


1999
1999


Project history

Israeli 'Super Dvora Mk 2' class. Aluminium construction.

Modernizations

none.

Naval service

No significant events.
