Tabuk 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
بدر [Badr]	612		Tacoma Boat, Tacoma, USA	30.5.1979	26.1.1980	28.9.1981	in service (2019)
اليرموك [Al Yarmook]	614		Tacoma Boat, Tacoma, USA	13.12.1979	13.5.1980	10.5.1982	in service (2019)
حطين [Hitteen]	616		Tacoma Boat, Tacoma, USA	19.5.1980	5.9.1980	12.10.1982	in service (2019)
تبوك [Tabuk]	618		Tacoma Boat, Tacoma, USA	22.9.1980	18.6.1981	10.1.1983	in service (2019)

Technical data

Displacement standard, t	900
Displacement full, t	1035
Length, m	74.7
Breadth, m	9.60
Draught, m	2.59
No of shafts	2
Machinery	CODOG: 1 General Electric LM-2500 gas turbine / 2 MTU 12V652 TB91 diesels
Power, h. p.	23000 / 3000
Max speed, kts	30
Fuel, t	diesel oil
Endurance, nm(kts)	4000(20)
Armament	2 x 4 Harpoon SSM (8 RGM-84C), 1 x 1 - 76/62 Mk 75, 1 x 6 - 20/76 Phalanx Mk 15, 2 x 1 - 20/70 Mk 10, 1 x 1 - 81/12 M29 mortar, 2 x 1 - 40/19 Mk 19 grenade launchers, 2 x 3 - 324 Mk 32 mod.5 TT (Mk 46 mod.2)
Electronic equipment	SPS-40B, SPS-55, Mk 92, Mk 90 radars, SQS-56 sonar, SLQ-32(v)1 ECM suite, 2x Mk 36 SRBOC decoy RL
Complement	58

Standard scale images

Graphics

Project history

US PCG1 type, ordered in 1977. Powerfully armed for their size and equipped with modern US electronics. Ships were completed with 25% overweight.

Modernizations

2001-2002, all: + Safire e/o system

Naval service

No significant events.
