Krasnaya Zvezda

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Хивинец [Khivinets], 12.1922- Красная Звезда [Krasnaya Zvezda]			New Admiralty, St. Petersburg	9.1904	11.5.1905	1906	depot ship 6.1928

Technical data

Displacement normal, t	1360
Displacement full, t
Length, m	69.8 pp 70.5 oa
Breadth, m	11.3
Draught, m	3.30 norm 3.45 max
No of shafts	2
Machinery	2 VTE, 8 Belleville boilers
Power, h. p.	1400
Max speed, kts	13.5
Fuel, t	coal 250
Endurance, nm(kts)	2070(9)
Armour, mm	steel; CT: 45
Armament	2 x 1 - 120/43 Canet, 8 x 1 - 75/48 Canet, 3 x 1 - 7.6/94
Complement	161

Standard scale images

Graphics

Project history

Designed for service in Mediterranean Sea and Persian Gulf. First Russian ship arranged with air-conditioning system for crew accommodation.

Ship protection

Only CT had armour protection.

Modernizations

1916: - 8 x 1 - 75/48, 3 x 1 - 7.6/94; + 2 x 1 - 120/43 Canet, 2 x 1 - 47/40 Hotchkiss AA

1920: - 4 x 1 - 120/43; + 4 x 1 - 130/53

Naval service

No significant events.
